Multirotor, multicopter and quadcopter discussion - The Drone thread

Brutal biff said:
The more videos I watch on 250 size racing quads the more tempted I am to get 1

Can these be used with 3s 5500 mah lipo?
Click to expand...

Bit heavy to be honest, you will need something more like 1300-1500mah 35c 3 or 4s. They're not expensive though (£10ish) and you should get 5 or 6 minutes of hooning around off a battery, more if you're just cruising.

If you've already got FPV stuff, there are cheap kits on banggood and aliexpress for less than £150........

gandhi said:
Bit heavy to be honest, you will need something more like 1300-1500mah 35c 3 or 4s. They're not expensive though (£10ish) and you should get 5 or 6 minutes of hooning around off a battery, more if you're just cruising.

If you've already got FPV stuff, there are cheap kits on banggood and aliexpress for less than £150........
Click to expand...

seen 1 I like everything apart apart from radio gear for £89 I am going invest in a bigger monitor though I would like goggles but my eyesight is as about as good as Mr Maggoo without my glasses

Any other sites you can recommend for quad gear that's uk based I got highly stung from customs using hobbyking

Yeh they are pretty cheap, bonus is they dont take massive amount of time to charge.

I am looking at FPV antennas, I was going to go for some decent ones that someone selling for 30 quid but I can gaurentee its not going to last long, so instead I think I am going to go for the spironet mushroom sort as these are apparently good range and durable? durable being the main point here.

I'm going to have to get a RP-SMA converter though as ideally I want to use this with my fatshark VTX also.

my VTX on the 250 is using RP-SMA (Eachine 200mw) where as my fatshark headset is SMA (250mw) I also have a 250mw fatshark vtx


Quick video from yesterday, nothing special, although you can see the differences in my flips etc they use to be much slower, but now as I have increased the rate wham, nice flip :)

I still have more to do to get the wobble out.


Last edited:
Just about to order some 250 bits,

How does this sound?

Naze acro,
MultiStar & Afro Combo Pack - 2206 Baby Beast Motor and 12A Afro ESC Set of 4 CW/CCW.
H-King Color 250 Class FPV Racer Quadcopter Frame
Turnigy nano-tech 1300mAh 4S 25~50C
Gemfan 5030

I have FPV and radio already.

Brutal biff said:
seen 1 I like everything apart apart from radio gear for £89 I am going invest in a bigger monitor though I would like goggles but my eyesight is as about as good as Mr Maggoo without my glasses

Any other sites you can recommend for quad gear that's uk based I got highly stung from customs using hobbyking
Click to expand...

Might be worth having a look at either the headplay or quanum v2 goggles - both will let you wear glasses. The quanums (sp?) are only about £50 from HK and they had them in stock at the UK warehouse. In fact, the UK warehouse stock most bits for a 250 now.

Failing that, makeitbuildit are very good.

DJMK4 said:
I am looking at FPV antennas, I was going to go for some decent ones that someone selling for 30 quid but I can gaurentee its not going to last long, so instead I think I am going to go for the spironet mushroom sort as these are apparently good range and durable? durable being the main point here.

I'm going to have to get a RP-SMA converter though as ideally I want to use this with my fatshark VTX also.

my VTX on the 250 is using RP-SMA (Eachine 200mw) where as my fatshark headset is SMA (250mw) I also have a 250mw fatshark vtx
Click to expand...

Have a look at these antennas Lifetime guarantee. I've got a set and they are very good. Not quite up to the IBcrazy bluebeam ones but much more sturdy!

Try adding some TPA if you haven't already, that should help with the vibes although you might want to reduce P as well :)

gandhi said:
Might be worth having a look at either the headplay or quanum v2 goggles - both will let you wear glasses. The quanums (sp?) are only about £50 from HK and they had them in stock at the UK warehouse. In fact, the UK warehouse stock most bits for a 250 now.

Failing that, makeitbuildit are very good.



Have a look at these antennas Lifetime guarantee. I've got a set and they are very good. Not quite up to the IBcrazy bluebeam ones but much more sturdy!

Try adding some TPA if you haven't already, that should help with the vibes although you might want to reduce P as well :)
Click to expand...


Will note down and do another test flight :)



Ta

Below are the pids from the video

Video



Name: Proportional Integral Derivative

ROLL 3.6 0.060 60

PITCH 3.6 0.060 60

YAW 8.0 0.255 50

ALT 5.00 0.000 0

VEL 12.000 0.045 1

Pos 0.11 0.00 (N/A)

PosR 2.0 0.08 0.045

NavR 1.4 0.20 0.080

LEVEL 9.00 0.010 100

MAG 4.00 N/A N/A


Profile
2

Roll rate 0.60

Pitch Rate 0.60

Yaw Rate 0.15

TPA 0.60

Last edited:
Cant think what that store is, iv always used hobbyking but its a pain waiting for stuff to come back in to stock.

The last batteries I purchased were for my bixler 2 however I got them from Giantshark which were having a sale as they were closing down. They wont have any more stock though

A few shots i took from Overstrand in North Norfolk flying the inspire last Friday edited in Lightroom





And here is the video from it 1080p@60fps


Last edited:
^^ Brave flying over water!

If anyone was thinking of getting into 250 sized quads, this kit is pretty good value, has great quality components, proper carbon fibre, thick arms, PDB, FPV camera and rx. All you'd need would be batteries, a tx/rx (flysky fs i6?) and some quanum goggles/video rx and you'd be set. All in for around £250?

Also,

Don't buy turnigy branded lipos from anywhere other than HK. I've seen some horrendous markups on the HK prices. I'm all for supporting indie retailers but why would I pay 50% extra for batteries to save on an extra delivery charge?

FAO Rilot - Have you had a chance to try the head-plays yet? I've been hearing some pretty good things about the quanum V2 so I'm also tempted to try those!

gandhi

It flew great..its really no different than it falling out of the sky into a feild you will just be picking up pieces instead of a total loss (Depending on height of course)

gandhi said:
^^ Brave flying over water!

If anyone was thinking of getting into 250 sized quads, this kit is pretty good value, has great quality components, proper carbon fibre, thick arms, PDB, FPV camera and rx. All you'd need would be batteries, a tx/rx (flysky fs i6?) and some quanum goggles/video rx and you'd be set. All in for around £250?
Click to expand...

I've priced everything up apart from batteries to the tune of £150 that's frame motors ecs a devo reciever I've got the quanum goggles came as a full fpv kit for £65 with delivery and customs worked out a little over 100

I'm just using the goggles as a screen works fairly well For a 4 inch screen not great if you wear glasses as goggles tho I'm going mod them soon so they go over my glasses

Rebuilt my 250 for probably the 15th time, this time added some 3D printed parts (would have preferred red but didn't have any) and moved the D4R-II between the plates. Getting a bit on the heavy side so will be interested to see how it feels and how long I get out the batteries, will find out tomorrow.






spookywillow said:
Just about to order some 250 bits,

How does this sound?

Naze acro,
MultiStar & Afro Combo Pack - 2206 Baby Beast Motor and 12A Afro ESC Set of 4 CW/CCW.
H-King Color 250 Class FPV Racer Quadcopter Frame
Turnigy nano-tech 1300mAh 4S 25~50C
Gemfan 5030

I have FPV and radio already.
Click to expand...

Just ordered this lot from the HK UK warehouse as I didn't get any response to my above post.

Multistar Elite 2204-2300KV Multi-Rotor Motor x4
Afro Slim 20Amp Multi-rotor Motor Speed Controller x4
H-King Color 250 Class FPV Racer Quadcopter Frame (Black) x1
AfroFlight Naze32 Acro AbuseMark FunFly Controller x1
HobbyKing™ HKU5 5V/5A UBEC x1
Clear 5030 Propellers For Night Flying LED Illumination Set Of 4 (CW/CCW) x3
ZIPPY Flightmax 1800mAh 4S1P 40C x2
Turnigy nano-tech 1300mAh 4S 25~50C Lipo Pack x3
Turnigy Battery Strap 330mm x1

Total £177 including delivery and paypal currency conversion.

I'm sure I'm missing something :confused:

spookywillow said:
Just ordered this lot from the HK UK warehouse as I didn't get any response to my above post.

Multistar Elite 2204-2300KV Multi-Rotor Motor x4
Afro Slim 20Amp Multi-rotor Motor Speed Controller x4
H-King Color 250 Class FPV Racer Quadcopter Frame (Black) x1
AfroFlight Naze32 Acro AbuseMark FunFly Controller x1
HobbyKing™ HKU5 5V/5A UBEC x1
Clear 5030 Propellers For Night Flying LED Illumination Set Of 4 (CW/CCW) x3
ZIPPY Flightmax 1800mAh 4S1P 40C x2
Turnigy nano-tech 1300mAh 4S 25~50C Lipo Pack x3
Turnigy Battery Strap 330mm x1

Total £177 including delivery and paypal currency conversion.

I'm sure I'm missing something :confused:
Click to expand...

You are, a Transmitter, Receiver & Charger, unless you already have those that is.
