Project 'Candy Apple'








Hello again folks here we are with another Montymole Project The Nice People at BitFenix have sent me the Phenom ITX Case and 750W Fury PSU 8 Spectre Pro 120mm Fans and some LED's . Thank you for this package and I hope you like what I am going to do with it.



This Project shall be my gaming rig for while as Red Candy has been split down due to a few marks and chips on the paint work it will be re done in good time. It will be a short build log as the mods will be kept to minimum as the aim is to have nice clean and tidy compact rig that can be used for LAN's in the future.

The Hardware:
Intel i7 4770K
ASUS Z97 ITX Board
ASUS 780Ti GTX CUII
Corsair 16GB 2133 Vengeance Pro
BitFenix Fury 750W
BitFenix Phenom ITX
BitFenix Spectre Pro Fans

EK Supremecy CPU Block
EK 780Ti CUII Block
EK DCP4.0 Pump/Res Combo
EK 120mm PE Rad
EK Pastel Green Coolant
HW Labs 240mm Stealth
E22 Ultraclear
BitsPower 12mm OD Fittings
BitsPower Drain Tap

Mods :
Custom Full Acrylic side panels
MNPCTECH Billet Case Feet
Painting of Heatsinks on Motherboard & Backplate on GPU
Custom I/O Cover
Green Vandal Switch
Custom Painted SSD

Right now for some photo's

The Case out of the Box


Ok so this is a forum not play school so we all know how to use a screw driver



And A Drill




Nice PSU and no braiding to be done so there is 3 weeks saved or the money to pay PEXON :)


We all like sexy feet ....... or is that just me :p



Building has commenced










Some Hardware Porn





Right that is all we have for now but this will be updated again later tonight once I have got to the Cabin of Mods and done something with tools that make noises and lots of mess :)

Last edited:
The Lamptron Vandal Switch Installed

Hello again folks as I will not be using the original side panels I have had to use a Lamptron Vandal Switch for the On/Off Button So I took the center line from the BitFenix Logo and used a 19mm Wood Bit to make the hole





Braided the Lamptron Switch with E22 Teleios Fusion Green and Black





Installed the Front Rad



Fans wired up to a PWM board that is tucked away and will be covered with some acrylic to in fill and keep everything clean.


That's all for now folks :)

The Glowing Floor Panel

Hello again Folks I not done as much as I had hope to today but got something I am happy with. I will be needing some more LED Strips if that is OK BitFenix? ;)
So I took some 5mm Frosted White Acrylic sheet and cut a new floor panel for the front:


Used some off cuts of 3mm sold white Acrylic and Installed a BitFenix White Aqua Strip:


This is the outcome:






This little project looks like it will take a few more days due Got a few other bit of custom work to go into this before I can get the loop installed.

Let me know what you think so far bye for now :)

Dempsey22 said:
What you cutting the acrylic with ? I had great fun recently cutting custom panels for my build.... NOT :(
Click to expand...

With a Jigsaw and fine metal blade I am in need of a new one so a trip to Screw fix is on the card in the morning.

If you set up a straight edge like in the 1st pic in the last update it makes it easier :)

Wow, stunning, its builds like this that are making me seriously consider a smaller form factor for my next PC...
