The Pascal GTX 1080 Ti Owners Thread

The Artfull Bodger · 11 Mar 2017 at 18:33

Could have sworn i increased mv on my 1070 but had to wait for MSI afterburner beta before unlocking voltage became available

Doug2507 · 11 Mar 2017 at 18:51

BriT said:
You can't change the voltage on pascal cards.

You can.

Xereo · 11 Mar 2017 at 19:02

All sorted

Xereo · 11 Mar 2017 at 19:11

roysters said:
Is everyone apart from me putting this thing on water?? Are the all in one solutions as i haven't got a full system set up on water

Mine is on block already. 2060mhz, 45 degrees under full load.

rtho782 · 11 Mar 2017 at 19:13

I broke down and ordered the OcUK value founders model this afternoon. Not in stock right now, but hopefully next week I guess?

I might try to fit one of the EVGA hybrid coolers from my 980s on it.

Awahwah · 11 Mar 2017 at 19:17

rtho782 said:
I broke down and ordered the OcUK value founders model this afternoon. Not in stock right now, but hopefully next week I guess?

I might try to fit one of the EVGA hybrid coolers from my 980s on it.

Can you let me know the difference between your 980Ti SLI versus please? You have a similar setup to I.

rtho782 · 11 Mar 2017 at 19:23

Awahwah said:
Can you let me know the difference between your 980Ti SLI versus please? You have a similar setup to I.

I'm on 980 SLI, not 980ti SLI

BriT · 11 Mar 2017 at 19:27

Doug2507 said:
You can.

How?

The Artfull Bodger · 11 Mar 2017 at 19:27

trawetSluaP said:
Is the Voltage Slider and readout not available for you guys using Afterburner?

This is for information purposes only and I do not take any responsibility
Thanks to Guru 3D (http://www.guru3d.com/articles_pages/geforce_gtx_1080_ti_review,32.html):
Use any tweaking utility of your preference of course. We use AB, AfterBurner. If you cannot wait for a new AB reelase and need some voltage control, here's a tip:

Add the card to third party database yourself (edit MSIAfterburner.oem2 included in the last official build) then select third party voltage control mode in properties and adding the following will do the trick.

[VEN_10DE&DEV_1B06&SUBSYS_120F10DE&REV_??]
VDDC_Generic_Detection = 1
Our applied tweak:

Core Voltage : +50
Power Limit : 120%
Temp. limit : 90C
Core Clock : + 150
Memory Clock : +500 MHz (=11.1 GHz effective data-rate)
FAN RPM: 65%

Once overclocked keep this in mind: Due to the dynamic nature of the boost clock, your frequency is not fixed. Limiters and monitors, temperature, load, power and voltages will continuously alter a maximum clock state. The biggest limiter for the 1080 Ti FE would be temperature, once we increased that limiter to 90 Degrees C, the boost clock would go up fast (but at the cost of noise of course). The card is begging to be liquid cooled alright hence we increased fan RPM to 65%.

This card now boosts to just over the 2 GHz marker with the memory at 1.2 Ghz.

scubes · 11 Mar 2017 at 19:38

Xereo said:
Mine is on block already. 2060mhz, 45 degrees under full load.

That's amazing mate exellent .

IT Troll · 11 Mar 2017 at 19:45

Ran a few 3dMarks to measure the increase from my old 980 Ti SC. For these the 1080 Ti is at stock settings. The 980 Ti SC had a small factory overclock. Everything else is the same, except the drivers are slightly newer on the 1080 Ti.

3DMark 11 Extreme +52.8%
Fire Strike Extreme +57.8%
Fire Strike Ultra +57.1%
Time Spy +62%

Max Boost 1885
Max Temp 81
Max Fan 47% (auto)

I then went for a 2 GHz overclocked run on Time Spy.
Time Spy +72.6%
Max Clock 2038
Max Temp 87
Max Fan 55% (auto)

1kiwi · 11 Mar 2017 at 20:39

Wow those are some amazing performance gains

easyrider · 11 Mar 2017 at 21:01

Xereo said:
Mine is on block already. 2060mhz, 45 degrees under full load.

Is that on the cpu loop ?

Kaapstad · 11 Mar 2017 at 21:02

Welcome and TROH updated.

The Roll of Honour.

Date 11/03/2017, Make EVGA Founders Edition, Xereo, Link
Date 11/03/2017, Make EVGA Founders Edition, madindehead, Link
Date 11/03/2017, Make EVGA Founders Edition, Techen, Link
Date 11/03/2017, Make Asus Founders Edition, bemaniac, Link
Date 11/03/2017, Make EVGA Founders Edition, deFiniLoGy, Link
Date 11/03/2017, Make NVidia Founders Edition, roysters, Link
Date 11/03/2017, Make EVGA Founders Edition, Mean Mr Mustard, Link
Date 11/03/2017, Make Zotac Founders Edition, sk3lph, Link
Date 10/03/2017, Make NVidia Founders Edition, stooeh, Link
Date 10/03/2017, Make NVidia Founders Edition, IT Troll, Link
Date 10/03/2017, Make NVidia Founders Edition, RichardH754, Link
Date 10/03/2017, Make NVidia Founders Edition, RichL, Link
Date 10/03/2017, Make NVidia Founders Edition, traveyb, Link
Date 10/03/2017, Make NVidia Founders Edition, Amatyr, Link
Date 10/03/2017, Make NVidia Founders Edition, X-Mikuru_Beam-X, Link
Date 10/03/2017, Make NVidia Founders Edition, Robzere31, Link
Date 10/03/2017, Make NVidia Founders Edition, Speed, Link

To get on the Roll of Honour all you have to do is post a pic with your user name on it of your GTX 1080 Ti.

Xereo · 11 Mar 2017 at 21:39

easyrider said:
Is that on the cpu loop ?

Yes i have it on a CPU loop, but have 3 radiators

Xereo · 11 Mar 2017 at 21:43

Kaapstad said:
Welcome and TROH updated.

The Roll of Honour.

Date 11/03/2017, Make EVGA Founders Edition, Xereo, Link
Date 11/03/2017, Make EVGA Founders Edition, madindehead, Link
Date 11/03/2017, Make EVGA Founders Edition, Techen, Link
Date 11/03/2017, Make Asus Founders Edition, bemaniac, Link
Date 11/03/2017, Make EVGA Founders Edition, deFiniLoGy, Link
Date 11/03/2017, Make NVidia Founders Edition, roysters, Link
Date 11/03/2017, Make EVGA Founders Edition, Mean Mr Mustard, Link
Date 11/03/2017, Make Zotac Founders Edition, sk3lph, Link
Date 10/03/2017, Make NVidia Founders Edition, stooeh, Link
Date 10/03/2017, Make NVidia Founders Edition, IT Troll, Link
Date 10/03/2017, Make NVidia Founders Edition, RichardH754, Link
Date 10/03/2017, Make NVidia Founders Edition, RichL, Link
Date 10/03/2017, Make NVidia Founders Edition, traveyb, Link
Date 10/03/2017, Make NVidia Founders Edition, Amatyr, Link
Date 10/03/2017, Make NVidia Founders Edition, X-Mikuru_Beam-X, Link
Date 10/03/2017, Make NVidia Founders Edition, Robzere31, Link
Date 10/03/2017, Make NVidia Founders Edition, Speed, Link

To get on the Roll of Honour all you have to do is post a pic with your user name on it of your GTX 1080 Ti.

Take it i am the only Capetonian on there

Razor Time · 11 Mar 2017 at 21:48

IT Troll said:
Ran a few 3dMarks to measure the increase from my old 980 Ti SC. For these the 1080 Ti is at stock settings. The 980 Ti SC had a small factory overclock. Everything else is the same, except the drivers are slightly newer on the 1080 Ti.

3DMark 11 Extreme +52.8%
Fire Strike Extreme +57.8%
Fire Strike Ultra +57.1%
Time Spy +62%

Max Boost 1885
Max Temp 81
Max Fan 47% (auto)

I then went for a 2 GHz overclocked run on Time Spy.
Time Spy +72.6%
Max Clock 2038
Max Temp 87
Max Fan 55% (auto)

Nice boost in performance.

trawetSluaP · 11 Mar 2017 at 21:50

I have joined!

Disappointed with the amount of thermal throttling. Was expecting some but not as severe as it is! Would've thought Nvidia would have put a better cooler of their high-end cards. Lucky is going under water as soon as I get a block really!

rIcK · 11 Mar 2017 at 23:15

How are the FE coolers? I have a GTX1080 right now and a Micro ITX system, is the Ti much longer than a standard 1080?

trawetSluaP · 11 Mar 2017 at 23:16

rIcK said:
How are the FE coolers? I have a GTX1080 right now and a Micro ITX system, is the Ti much longer than a standard 1080?

Pretty sure they're identical physically accept for the lack of the DVI port.
