VGA to Displayport Adapter Help

panthro · 23 Jul 2020 at 19:11

Hi guys, need some help please. I've got an HP microserver that I'm trying to get running. It's got a VGA out but my monitor is DP and HDMI only. As I need to access the RAID controller and BIOS, I bought a VGA to displayport adapter but it doesn't seem to be picking up any signal. I've read that the adapter might need USB power? Any ideas on how to get it working and to pick up the VGA signal? Cheers.

brendy · 23 Jul 2020 at 19:29

Are you sure its VGA to DP and not DP to VGA? going from analogue to digital will need a power source at the VGA side to make it work, usually a little mini or micro USB port will be on it.

panthro · 23 Jul 2020 at 20:37

brendy said:
Are you sure its VGA to DP and not DP to VGA? going from analogue to digital will need a power source at the VGA side to make it work, usually a little mini or micro USB port will be on it.

It's one of these. There's no power supply on it.

https://www.ebay.co.uk/itm/363044249855

Joxeon · 23 Jul 2020 at 20:49

I think you will need something like this.

andy_mk3 · 23 Jul 2020 at 20:52

panthro said:
It's one of these. There's no power supply on it.

Features:

● Input Signal: Display Port

● Output Video: VGA

panthro · 23 Jul 2020 at 20:53

Lol that's solved that one then. Will buy a new one that's the right way round.
