Update on build was wating on psu but was DOA so otherwise finished (bar setting aida64).

Very nice! It’s a regular EVO case right not the XL? Asking as I have an EK Lumen on order and planning to fit where you have yours. Cheers,Dan.



[jammir]

Very nice! It’s a regular EVO case right not the XL? Asking as I have an EK Lumen on order and planning to fit where you have yours. Cheers,Dan.

Its normal EVO but you have to modifiy the case otherwise you have to install it a little higher or use the standoffs for the LCD.



[Thomasck]

nice and clean @jammir, congrats for the build!



[0121danwilliams84]

@jammir Thanks for that info. I imagine it looks better with screw holes you made I am guessing? I am not that handy even though I have built custom loops, when I get drills out bad things usually happen!



[jammir]

@jammir Thanks for that info. I imagine it looks better with screw holes you made I am guessing? I am not that handy even though I have built custom loops, when I get drills out bad things usually happen!

you dont need to make new holes there is a bit of metal that sticks up that needs to be bent out of the way or cut off but this will stop you installing the vertical gpu bracket



[0121danwilliams84]

you dont need to make new holes there is a bit of metal that sticks up that needs to be bent out of the way or cut off but this will stop you installing the vertical gpu bracket

Top class advice. I had to do something like that to fit an external rad in my H700 that is being retired. I know what the first thing I will be doing when the Lumen arrives now, desecrating the Evo it’s got to be done. Hopefully it’s easy to bend and doesn’t break off the rest of the case causing some apocalyptic event. Thanks for the pic as well.



[RedMogg]

Very nice! It’s a regular EVO case right not the XL? Asking as I have an EK Lumen on order and planning to fit where you have yours. Cheers,Dan.

Incredibly tidy build - could I ask what thickness radiators you've got? I think they're 45mm?



[V F]

Incredibly tidy build - could I ask what thickness radiators you've got? I think they're 45mm?

That's thicker than 45mm. It's the new EK XE Quantums at 58mm instead of 60mm Coolstream.



[Piotr]

My first build here. The focus of the build was on simplicity and performance.



[Mr Mcgoo]

Think it's safe to say you nailed the simplicity aspect. Just wish my cable routing was as good as yours for sure



[0121danwilliams84]

My first build here. The focus of the build was on simplicity and performance.

Liking the Bykski block. Waiting for one of those myself. I take it this is a 3000 series 3 pin PCIE card?



[Piotr]

Liking the Bykski block. Waiting for one of those myself. I take it this is a 3000 series 3 pin PCIE card?

Its KFA2 GeForce RTX 3090 HOF, Ill share the full specification in a spoiler.

Spoiler: Full specification

Watercooling specification

Rads:

• front: EK Water Blocks EK-Quantum Surface X480M + 4x Phanteks T30
• side: EK Water Blocks EK-Quantum Surface P360M X-Flow + 3x Noctua NF-A12x15
• top: EK Water Blocks EK-Quantum Surface P360M + 3x Phanteks T30

CPU Block: EK Water Blocks EK-Quantum Velocity² D-RGB - AM4 Nickel + Satin Titanium

GPU Block: Bykski N-GY3090HOF-TC,Dual Active GPU Backplane Block For GALAX RTX 3090 HOF

Res/Pump: Aquacomputer ULTITUBE D5 NEXT 150 PRO with Leakshield

Flow meter: Aquacomputer Flow sensor high flow NEXT

Tubing: EK Water Blocks EK-Tube ZMT Matte Black 9.5/15.9mm

Fittings: EK Water Blocks EK-Quantum Torque Satin Titanium

Temperature sensors: 2x Alphacool Eiszapfen temperature sensor 2xIG1/4 - chrome

Bulkheads: 2x Alphacool Apex Fillport - chrome

Water mix: Aquacomputer Double Protect Ultra Clear


PC specification

CPU: AMD Ryzen 9 5900x

GPU: KFA2 GeForce RTX 3090 HOF

RAM: G.Skill Trident Z Royal 64 GB, 4000MHz, CL18

MBoard: X570 AORUS MASTER

PSU: EVGA SuperNOVA 1000 P2

Case: Corsair 7000D Airflow

Cable riser: EK Water Blocks EK-Loop PCI-E 4.0 Riser Cable - 200 mm



[0121danwilliams84]

Its KFA2 GeForce RTX 3090 HOF, Ill share the full specification in a spoiler.

Spoiler: Full specification

Watercooling specification

Rads:

• front: EK Water Blocks EK-Quantum Surface X480M + 4x Phanteks T30
• side: EK Water Blocks EK-Quantum Surface P360M X-Flow + 3x Noctua NF-A12x15
• top: EK Water Blocks EK-Quantum Surface P360M + 3x Phanteks T30

CPU Block: EK Water Blocks EK-Quantum Velocity² D-RGB - AM4 Nickel + Satin Titanium

GPU Block: Bykski N-GY3090HOF-TC,Dual Active GPU Backplane Block For GALAX RTX 3090 HOF

Res/Pump: Aquacomputer ULTITUBE D5 NEXT 150 PRO with Leakshield

Flow meter: Aquacomputer Flow sensor high flow NEXT

Tubing: EK Water Blocks EK-Tube ZMT Matte Black 9.5/15.9mm

Fittings: EK Water Blocks EK-Quantum Torque Satin Titanium

Temperature sensors: 2x Alphacool Eiszapfen temperature sensor 2xIG1/4 - chrome

Bulkheads: 2x Alphacool Apex Fillport - chrome

Water mix: Aquacomputer Double Protect Ultra Clear


PC specification

CPU: AMD Ryzen 9 5900x

GPU: KFA2 GeForce RTX 3090 HOF

RAM: G.Skill Trident Z Royal 64 GB, 4000MHz, CL18

MBoard: X570 AORUS MASTER

PSU: EVGA SuperNOVA 1000 P2

Case: Corsair 7000D Airflow

Cable riser: EK Water Blocks EK-Loop PCI-E 4.0 Riser Cable - 200 mm

I like your style. I have an Aqua Computer Next as well and the same tubing. Looks beautiful, well done!



[mk1_salami]

Update on build was wating on psu but was DOA so otherwise finished (bar setting aida64).

Absolutely stunning. Well done.



[Parsley]

Not lit up or anything as this was taken during the last flush.

Only just managed to cram the rads in, and it's so damn heavy now. But at least it's nice and quiet!



[0121danwilliams84]

Very close to finishing my AM5 build now! Still have the tubes to do and spot the missing space for a GPU, I think an RTX 4090 might fit quite nice and snug in there



[0121danwilliams84]

Update on build was wating on psu but was DOA so otherwise finished (bar setting aida64).

Hey, just got around to installing the EK Lumen. Installed with the USB adapter to mobo that goes USB to USB type C into the Lumen. I get the EK logo but no display. Would I just be able to ask if that is how you have yours installed and if you may have any other advice? Have tried a few things in windows. It’s not recognised. Thanks! Edit: I didn't realise the other cable provides video, so an easy fix hopefully! The product page makes it sound like you just use one cable and the other HDMI to USB was for external use.



[dazzlaa]

Update on build was wating on psu but was DOA so otherwise finished (bar setting aida64).

That is a lovely build. I haven’t see a GPU mounted that way before either. Is this customised or is a bracket for that mount available to buy?



[jammir]

That is a lovely build. I haven’t see a GPU mounted that way before either. Is this customised or is a bracket for that mount available to buy?

o11 EVO has a bracket to mount on that side.



[jammir]

Hey, just got around to installing the EK Lumen. Installed with the USB adapter to mobo that goes USB to USB type C into the Lumen. I get the EK logo but no display. Would I just be able to ask if that is how you have yours installed and if you may have any other advice? Have tried a few things in windows. It’s not recognised. Thanks! Edit: I didn't realise the other cable provides video, so an easy fix hopefully! The product page makes it sound like you just use one cable and the other HDMI to USB was for external use.

The usb is only for power and you have to use the hdmi for video I have a thunderbolt 4 to hdmi cable which I use for video.
