Case Complete

chiLLZ · 27 Jul 2009 at 19:33

This is a modded pc7 case for my i7 system, I have used Lian LI pc7 cases for years because I like them so much. I wanted to modernise it a bit by getting rid of the floppy drive spaces and creating a 120mm fan space at the top and improve cable management. Also the hard drive cage is gone to allow the videocards to get air. The four hard drives are in the DVD drive bay turned to the side.

-

Lemin · 27 Jul 2009 at 19:45

Well done, looks great.

RJC · 27 Jul 2009 at 20:10

Looks good

What are the temps like on the gpu.

moppy89 · 27 Jul 2009 at 20:11

Very neat

EdAllonby · 27 Jul 2009 at 20:13

Impressive! I like the simplicity look. 3graphics cards too! phewww

millsy888 · 27 Jul 2009 at 20:15

Looks very neat and simplistic. Nice setup

chiLLZ · 27 Jul 2009 at 20:28

thanks everyone, the videocard temps are fine now as they are undervolted, i have not seen them go above 90c but when they had the origional bios and i first put them in this case one hit 115c before the system crashed, then i found i needed to cut an air exit below the pci slots because the bottom videocards air exit was blocked because the case does not have enough pci card spaces. also the bottom card gets air from under the case through a filter. - really hard work lol :eek:

Monkey Puzzle · 27 Jul 2009 at 20:41

Great job - very slick.

EdGey · 27 Jul 2009 at 21:00

looks awesome

good job

There's got to be somewhere to hide that 24 pin cable though.

zia · 27 Jul 2009 at 21:07

Very nice indeed,what it like noise wise? must hum a bit?

zia

chiLLZ · 27 Jul 2009 at 21:10

yeah it does, i am thinking of getting some 1300 rpm yate loon fans, these are 1700, its not too bad though, you can hear the air being forced through the filters at the front more though

mjones1 · 27 Jul 2009 at 22:31

Very nice tri sli set up and very neat!

Kennysevenfold · 27 Jul 2009 at 22:33

Sexual i have to say

morkfromork · 27 Jul 2009 at 22:46

I'm liking this a lot. Good job done there.

chiLLZ · 28 Jul 2009 at 01:36

EdGey said:
There's got to be somewhere to hide that 24 pin cable though.

yeah thats been bugging me, its too thick to tuck behind the mobo tray because it just bends the motherboard and the tray and the side of the case, also theres just no place with all the hdd cables and gpu power cables. i guess it could be done if the cable was modified with more felxable wires but i hate messing with power supplies. oh well

Helios1234 · 28 Jul 2009 at 01:49

Impressive! And very tidy!

Hughsy · 28 Jul 2009 at 03:17

I did not even reliase there were 3 cards in your system at first, thats how tidy it looks.

CreAtiv3 · 28 Jul 2009 at 10:20

Im doing somthing similar to an old CoolerMaster ATCS 200 but cannot find any mesh/grill for the front that looks half decent.

Is that the AC Ryan meshx stuff you've used?

jamesgoss · 28 Jul 2009 at 10:23

That looks absolutely amazing, really original

chiLLZ · 28 Jul 2009 at 10:28

I used a sheet of perforated aliminum from here, cant remember which one.

http://uk.rs-online.com/web/search/...Attribute=Grade 3103 H14 Aluminium#breadCrumb

the ac ryan stuff is always sold out

thanks for all the positive comments everyone
