Help With Memory Tune

[Ad_Augendae]

I got 4 sticks of 8Pack 3200 c14.14.14.31 and need someone to take a look over the settings to see if I have done anything silly.
3200 C16 seems ok, will the below voltages etc be ok, XMP wouldn't boot as expected!



[JollyJamma]

Set your DOC voltage to 1.1 and try XMP again.

I’ll post a DDR4 overclocking guide that’ll give you an easy timings and voltage breakdown and get that running at full speed no problem.

You can even go in and tweak tertiary timings for a little extra speed.
