First Custom Loop in a Define 7

Thanks, I'll open my fill port that is in the top of the chassis, then open the drain port and see how it goes. I could blow into the loop to get a bit more out if needed.

5700 XT added to the loop and the chipset block, running very quiet and cool now.

Pictures.


Drain port worked well, I did have to tip the case a little to help remove some extra fluid.



Loop drained and connectors removed ready to remove the motherboard. Removed the return on the top of the res as this will be moved to the bottom inlet.



The X570 chipset that is just asking for a water block.



Time to void the warranty and get this guy under water.



Many screws.



The TIM was very dry and crusty.


Block attached, back plate pads going on.



The new loop is in, time for some leak testing.



Done.


Chipset block tucked under the GPU.


Panel off, photo from across the desk.






Got the wider lens out.



Love the texture of the back plate.



Panel on.

Last edited:
Thought I'd post the full spec list and the photo set I took yesterday.

PC Spec

Case: Fractal Design Define 7 Mid-Tower Case - Gunmetal Grey Light Tint Tempered Glass
Motherboard: Gigabyte Aorus Elite X570
CPU: 3900x
GPU: Asus 5700 XT
RAM: 32GB 3600hmz Corsair LPX
Fans: - 6 x Noctua NF-F12 chromax
- 1 x Noctua NF-A12x15
Rads: - EK Water Blocks EK-CoolStream PE 360 (Triple Fan) Radiator
- XSPC EX360 Crossflow Radiator V2
Blocks: - EK Water Blocks EK-Velocity Digital Addressable RGB AMD CPU Water Block - Nickel + Plexi
- EK Water Blocks EK-Vector Radeon RX 5700 +XT RGB Graphics Card Water Block- Nickel + Plexi + Back plate
- EK-Quantum Momentum Chipset Aorus X570
Res/pump: EK Water Blocks EK-Quantum Kinetic TBE 200 D5 PWM D-RGB Pump / Reservoir Combo - Plexi
Fittings: EK-AF black x many
PSU: Seasonic Focus PX-750 750W 80+ Platinum
Storage: - 1TB ROCKET NVMe PCIe M.2 2280 Internal SSD High Performance Solid State Drive
- 1TB 860 EVO SSD 2.5" SATA 6GBPS 64 LAYER 3D V-NAND SOLID STATE DRIVE
Misc: - Mayhems X1 Clear Premixed Watercooling Fluid
- Mayhems Ultra Clear Watercooling Tubing (3/8 - 5/8) 16/10mm
- EK Water Blocks EK-UNI Pump Bracket (120mm FAN)
- Phanteks Extension Cable Combo Kit - Black/Grey
- Thermal Grizzly Kryonaut High Performance Thermal Paste

Peripherals

Keyboard: Durgod Hades 68 - Gateron silent browns - custom PBT keycaps
Mouse: Glorious Gaming Model D matte black
Mat: Cooler master MP510 XL
Speakers: Kanto YU2 with S2 stands
Sub: Kanto SUB6 matte white (undet the desk).
Headphones: Philips SHP9500 + Boomprod mic
Monitor mount: Duronic Single Monitor Arm Stand DM351X1
Monitor: LG 27GL850-B
























Last edited:
MikeTimbers said:
how much do the temps drop if you remove the front panel?

I have a DefineS and the front panel really affects temps.
Click to expand...

I haven't tried tbh, the temps are really good so haven't had to do anything extra. I have the door open on the case when gaming and the fans at 1000RPM, GPU is at mid 50s and same for CPU.
