First Ever Build..!

Mathematics · 5 Nov 2013 at 12:40

First Ever Build...!
My first build is about to commence.! Got everything here ready, except 2 asaka vipers which should be here tomorrow.

I have the following components:

Amd FX8320
Asus crosshair V formula-Z
Asus HD7990
Asus PCE-AC68 wireless card
Samsung SSD 250GB
Seagate 3TB HDD x 2
Kingston HyperX Genesis 4GB (1600) x 2
Corsair Carbide 500r
Corsair AX850
Corsair H100i
Sentry 2 Fan Controller
6 fans (scythe and noctua)
2 fan guards
1 fan filter
Fan pins and washers
Samsung optical drive
Prolimatech nano 3 thermal paste
Windows 7
Aula keyboard, mouse and mat.

First question..how to upload pics lol

Mathematics · 5 Nov 2013 at 12:45

Don't have permission to post pics so they will follow..

DaleTheWhale · 5 Nov 2013 at 13:03

Looks tasty, can you not embed images in your post like such:

[ img] [/img ] < Removing the spaces.

Fulax · 5 Nov 2013 at 16:16

Upload here: http://imgur.com/

Then

ThaReaperGuy said:
embed images in your post like such:

[ img] [/img ] < Removing the spaces.

Good luck

Mathematics · 5 Nov 2013 at 16:18

Having an absolute nightmare here! Lol

Will try and upload pics now.

Do I need all the PSU connectors in because there's a lot of them!

JoeF1 · 5 Nov 2013 at 16:20

No mate, just ones that you need to power the HDDs, GFX cards etc. Rest put in the box for safe keeping

Mathematics · 5 Nov 2013 at 16:29

Mathematics · 5 Nov 2013 at 16:32

Fulax · 5 Nov 2013 at 16:32

[/img], not [img/]

When you view an uploaded picture there should be a bunch of links to the right of it. Copy and paste the BBCode one into your post.

Mathematics · 5 Nov 2013 at 17:15

Question.!

My SSD, HDD and Optical drive all have Sata connectors, so I have connected them but I don't know where they go on the motherboard, there is a red station where all the ports go but does it matter where I plug them in, there are 8 sata ports on the red station on the mobo.

daveip · 5 Nov 2013 at 17:16

No doesn't really matter where they go/what order they go in to the board.

Mathematics · 5 Nov 2013 at 17:18

Cheers mate! I put the Ssd in port 1 and optical in port 2 then, leaving the HDDs out at the moment, can rearrange later..

Mathematics · 5 Nov 2013 at 17:21

Where do I plug the fans in the H100i? I have the other 4 in the sentry fan controller, and another 2 already connected to the case controller.

Mathematics · 5 Nov 2013 at 17:24

In the side of the H100i socket head, there is a port of some kind, not for fans, anyone know what it's for..?

Fulax · 5 Nov 2013 at 17:24

The h100i comes with a cable with two 3 or 4-pin (can't remember which) connectors - put the other end in the pump.

You can also attach them to a fan header on your motherboard.

The mini-USB socket on the side of the pump is for the Corsair Link cable. You can use it to change the colour of the LED on the pump, but it doesn't need to be in for the pump to work.

tamzzy · 5 Nov 2013 at 20:22

Mathematics said:

Mathematics · 5 Nov 2013 at 23:23

Mathematics · 5 Nov 2013 at 23:27

http://imgur.com/NC7XFHv

http://imgur.com/VFpSy3f

http://imgur.com/EVSYBL0

Mathematics · 5 Nov 2013 at 23:30

Mathematics · 5 Nov 2013 at 23:31

I give up!

Still haven't finished the build, will start over tomorrow...thanks for the help guys
