AMD Ryzen 7 9800X3D

  • Thread starter Thread starter Hostile_18
  • Start date Start date
Defy Belief said:
From a gaming perspective...

7600XT is £299.99, 7800XT is £419.99, not even gonna do the math about how much better a 7800XT is than a 7600XT in terms of performance.

GPUs get this rep all the time of being overpriced and negligible performance gains, people in here going crazy they cant get hold of a chip that is about 5-8% faster in gaming (With a 4090..) than a chip that was £300 2 months ago...
Click to expand...
This is a really good post and the 7600XT to 7800XT upgrade really puts it into perspective.


7800XT is 62% faster. :cool:

have you watch the jay2cents overclocking vid? 1% lows beating the highs of everything else lol


LtMatt said:
My first sample arrived. SP112, possible indication of not the strongest cores. That said, appears to have a nice strong IMC. 8300C34 low VDD tune right off the bat looking good.



Excuse the finger print. :p

I did some benchmarks on Cyber and FC6 on my 9950X before I pulled it out last night, so will have something to compare to.
Click to expand...
LtMatt said:
First bench for you degenerates.

PBO -49 All core.

CB23
Click to expand...
LtMatt said:
Some Cyberpunk 2077 results, first run on a 9800X3D. Turbo mode disabled.

9800X3D SMT On Partially Tuned: 379.31 FPS

9950X SMT Off Fully Tuned: 315.13 FPS

Note: SMT Off for the 9950X is beneficial to performance in Cyberpunk 2077.
Click to expand...
Final result of tuning, forget running high memory frequency on single CCD X3D, focus on running MCLK/UCLK in 1:1 mode and as high as it'll go, with FCLK also running as high as it'll go.

If you get lucky, you'll get 6800Mhz + 2200Mhz FCLK. 6600Mhz should be more easily achievable now. Failing that, 6400Mhz.

Of course you need to test everything for stability, so don't try and blindly copy my settings etc.



9800X3D SMT On 6800MhzC28 / 2200Mhz FCLK 1:1: 390.71 FPS


-----



9800X3D SMT On 8300MhzC34 / 2200Mhz FCLK 1:2: 379.31 FPS


Now to experiment with manual voltage and clock frequency control.

Last edited:
Quick and dirty tuned, low volts 8000 C36 on an Asus B650E-E
This is not a top end ram kit, just a very ordinary Teamgroup T Create 6400 48gb kit with Hynix 24M die IC's. No fan blowing on them, nothing.

imgur.com

8000 C36

Discover the magic of the internet at Imgur, a community powered entertainment destination. Lift your spirits with funny jokes, trending memes, entertaining gifs, inspiring stories, viral videos, and so much more from users.
imgur.com imgur.com

I agree with Matt, my 6400 1:1 tune smokes this.
Just remember not every CPU, Motherboard and ram kit will do these speeds.
If you are not a tweaker, play it safe with a 6000 / 6200 CL28 or CL30 kit.

LtMatt said:
Final result of tuning, forget running high memory frequency on single CCD X3D, focus on 1:1 FCLK and run memory as high as it'll go. If you get lucky, you'll get 6800Mhz. 6600 should be more easily achievable now. Failing that, 6400Mhz.



9800X3D SMT On 6800MhzC28 / 2200Mhz FCLK 1:1: 390.71 FPS


-----



9800X3D SMT On 8300MhzC34 / 2200Mhz FCLK 1:2: 379.31 FPS


Now to experiment with manual voltage and clock frequency control.
Click to expand...

Not sure if my ram (CL30 6000 GSkill) will run that high. With my 7800X3D, I tried to get 6400mhz many times, but could never get it stable. Even at 6200 it was very rocky and threw errors.

Finally got it stable at 6000 CL28 gear down disabled and very tight subs.

Depends on the IMC and individual chip I suppose, but going by my experience with the 7800X3D and my ram, I’d be surprised if I got 6400/6600.

Is it really worth trying to get more than 6000CL28 with gear down disabled? I’m more than willing to tinker etc if it is, but not sure if it is overall.

Last edited:
matty007 said:
Not sure if my ram (CL30 6000 GSkill) will run that high. With my 7800X3D, I tried to get 6400mhz many times, but could never get it stable. Even at 6200 it was very rocky and threw errors.

Finally got it stable at 6000 CL28 gear down disabled and very tight subs.

Depends on the IPC and individual chip I suppose, but going by my experience with the 7800X3D and my ram, I’d be surprised if I got 6400/6600.

Is it really worth trying to get more than 6000CL28 with gear down disabled?
Click to expand...
A 6000CL28 configuration with tight sub-timings and GDM disabled is promising. You might squeeze out a bit more performance by running at a higher frequency, but it's all about finding the right balance to see what your memory and CPU are capable of. I'm utilizing a binned Hynix A Die kit, so your results may differ.

LtMatt said:
A 6000CL28 configuration with tight sub-timings and GDM disabled is promising. You might squeeze out a bit more performance by running at a higher frequency, but it's all about finding the right balance to see what your memory and CPU are capable of. I'm utilizing a binned Hynix A Die kit, so your results may differ.
Click to expand...

Yeah, did seem a bit strange that I couldn’t really get 6200/6400 stable but achieved it with gear down disabled and very tight at 6000 lol. Guess that probably points to the IMC or chip itself having a limitation rather than the ram.

Was just going to apply my current settings to the 9800X3D and see if it’s stable, but if there’s really benefit in going higher, then I’ll try it. I enjoy memory tuning.

Will be interesting to see if the new chip allows me to get the ram higher.

Mine is M-Die.

Last edited:
matty007 said:
Yeah, did seem a bit strange that I couldn’t really get 6200/6400 stable but achieved it with gear down disabled and very tight at 6000 lol. Guess that probably points to the IMC or chip itself having a limitation rather than the ram.

Was just going to apply my current settings to the 9800X3D and see if it’s stable, but if there’s really benefit in going higher, then I’ll try it. I enjoy memory tuning.

Will be interesting to see if the new chip allows me to get the ram higher.

Mine is M-Die.
Click to expand...
Maybe. It would probably work with the right combination of timings, voltages, and resistances set in the BIOS. You just have to know what to set and which timings to slacken off. Comes with practice. I’d be amazed if you couldn’t do at least 6200C30 with a little patience.

Missed a few pages, but what's the highest boost anyone has seen? And does it make much difference in real world performance? :)
