Home Assistant beginners

john_smith · 10 Dec 2022 at 07:29

Really. Cool. I’ll try my synology creds. Thank you. I never consider that!

john_smith · 10 Dec 2022 at 07:48

bash-5.1# login
ha login: synology
Password:
Login incorrect
ha login: ha
Password:
Login incorrect
ha login: root
Login incorrect
bash-5.1# login
ha login: admin
Password:
Login incorrect

That's using the credentials I use to login to DSM

john_smith · 10 Dec 2022 at 08:17

Ok, i'm rolling. Gave up using the docker terminal from within DSM...just enabled ssh on the nas and now i'm in. Running the scripts to get hacs installed and there's no zip on a synloogy, just 7z. More googling to work out how to do that and gave up.

In the end this thread solved it for me. I could manually download the hacs zip and reading the scripts workled out where they should be extracted to.

https://www.synology-forum.nl/firmware-algemeen/error-unzip-is-not-installed-via-ssh-op-ds/15/ I ca't understand a word of Dutch.

Semple · 10 Dec 2022 at 08:32

Bluecube said:
I use the Sonoff Zigbee 3 stick. I had random issues with the Conbee 2 but the Sonoff has been rock solid.

Just curious what issues you've had with the conbee2?

Harnser · 10 Dec 2022 at 10:17

The1nonly1 said:
I can't remember if it is fanless or not, it's really slim so I assume it's not. It's rated at 35w so over a month, roughly 26kWh if maxed. For the Coral, I have the USB version which took about 8 months to actually get it.

Thanks, as I want to use HA to collect temperature data rather than automate the home the running costs are a big factor. With a Pi4 drawing 5W, so let's say 10W at the plug allowing for an inefficient power supply... the cheapness of a second hand device still saves enough to cover the energy usage I guess

andy_mk3 · 10 Dec 2022 at 10:52

Semple said:
Just curious what issues you've had with the conbee2?

I switched from a Conbee II this week to a Sonoff Zigbee 3.0 (the later ‘E’ model). I found with my Conbee when I hit over 50 devices, occasionally I had small issues with commands not being sent. One example being the 4 GU10 Hue bulbs in the kitchen, I would often find one or two still turned on after they’d all been turned off. It’s not happened since switching but it’s only been a couple of days so far.

katie279 · 10 Dec 2022 at 11:31

john_smith said:
Ok, i'm rolling. Gave up using the docker terminal from within DSM...just enabled ssh on the nas and now i'm in. Running the scripts to get hacs installed and there's no zip on a synloogy, just 7z. More googling to work out how to do that and gave up.

In the end this thread solved it for me. I could manually download the hacs zip and reading the scripts workled out where they should be extracted to.

https://www.synology-forum.nl/firmware-algemeen/error-unzip-is-not-installed-via-ssh-op-ds/15/ I ca't understand a word of Dutch.

Glad you got it sorted - apologies, that's what I thought you meant originally - missed the docker part. I must confess I've never quite grasped Docker myself - I know it's meant to make everything easy, but seems to introduce more complexity to me - like above!

Anyway, you're away!

andy_mk3 · 10 Dec 2022 at 11:36

katie279 said:
Glad you got it sorted - apologies, that's what I thought you meant originally - missed the docker part. I must confess I've never quite grasped Docker myself - I know it's meant to make everything easy, but seems to introduce more complexity to me - like above!

Anyway, you're away!

Docker is pretty amazing. I'm not really a fan of docker terminal, but when you have something like unraid where it's implemented really well, it makes it so easy to use. I have 30 or more containers running now it’s brilliant.

dlockers · 10 Dec 2022 at 11:48

Is anyone exposing HA over the internet without the 60 quid a year sub?

john_smith · 10 Dec 2022 at 12:49

katie279 said:
Anyway, you're away!

Ok, how do I get my solar generation numbers into pvoutput?

Publishing solar production data to pvoutput.org from Home Assistant

PVOutput is a website in which you can share your solar production data. Home Assistant is an open source home automation solution that can be run in Raspberry Pi among other options. Sharing photo…

javiermugueta.blog

I've followed that and then I get to step 4. I feel step 4 and 5 need several more steps as for a n00b like me i'm completely lost.

The1nonly1 · 10 Dec 2022 at 13:03

dLockers said:
Is anyone exposing HA over the internet without the 60 quid a year sub?

There a few different ways of doing this. Cloudflare or DucKDNS seem the most popular.

The Easiest Free Way To Do Home Assistant Remote Access!

I have covered quite a few different remote access solutions for Home Assistant, either through port forwarding or setting up VPNS but recently, it has emerg...

youtu.be

Home Assistant Remote Access for FREE - DuckDNS + LetsEncrypt + Single URL

In this video I will show you step by step everything you need to know to get remote access working on your Home Assistant, from setting up a free domain nam...

youtu.be

andy_mk3 · 10 Dec 2022 at 13:07

dLockers said:
Is anyone exposing HA over the internet without the 60 quid a year sub?

Yep, Cloudflare DNS (Dymanic DNS run by a plugin on OPNsense to keep my IP updated), then use NGINX Proxy Manager.

john_smith · 10 Dec 2022 at 13:17

john_smith said:
Ok, how do I get my solar generation numbers into pvoutput?

Publishing solar production data to pvoutput.org from Home Assistant

PVOutput is a website in which you can share your solar production data. Home Assistant is an open source home automation solution that can be run in Raspberry Pi among other options. Sharing photo…

javiermugueta.blog

I've followed that and then I get to step 4. I feel step 4 and 5 need several more steps as for a n00b like me i'm completely lost.

Step 4.

Message malformed: extra keys not allowed @ data['shell_command']

katie279 · 10 Dec 2022 at 14:40

john_smith said:
Ok, how do I get my solar generation numbers into pvoutput?

Publishing solar production data to pvoutput.org from Home Assistant

PVOutput is a website in which you can share your solar production data. Home Assistant is an open source home automation solution that can be run in Raspberry Pi among other options. Sharing photo…

javiermugueta.blog

I've followed that and then I get to step 4. I feel step 4 and 5 need several more steps as for a n00b like me i'm completely lost.

Hi John,

No worries - probably the quickest way is to just add it to your configuration.yaml file. Do you know where this is? (I can walk you through if not).

Below is what I have in my configuration.yaml file - just paste it right at the bottom and change the bits in caps to your ID and API Key

Code:

## Solar Output to PV Output
shell_command:
  pvoutputcurl: >
    curl -d "d={{now().strftime("%Y%m%d")}}"
         -d "t={{now().strftime("%H:%M")}}"
         -d "v1={{ (states('sensor.pv_energy_today') | float * 1000)  | int }}"
         -d "v2={{ states('sensor.pv_power') }}"
         -d "v6={{ states('sensor.grid_voltage') }}"
         -H "X-Pvoutput-SystemId: MY SYSTEM ID"
         -H "X-Pvoutput-Apikey: MY API KEY IN HERE"
         https://pvoutput.org/service/r2/addstatus.jsp

katie279 · 10 Dec 2022 at 14:42

andy_mk3 said:
Docker is pretty amazing. I'm not really a fan of docker terminal, but when you have something like unraid where it's implemented really well, it makes it so easy to use. I have 30 or more containers running now it’s brilliant.

Yeah I know it's almost certainly me! Just never had the time to dig in/get my head around it - maybe partly as it's solving a problem I don't have, everything runs flawlessly as it is for me! One day I'll get a quiet moment - however today I'm adding all the Home Assistant sensors/controls for our new Tesla! Absolutely amazing range of controls/sensors it has for HA!

andy_mk3 · 10 Dec 2022 at 14:47

katie279 said:
Yeah I know it's almost certainly me! Just never had the time to dig in/get my head around it - maybe partly as it's solving a problem I don't have, everything runs flawlessly as it is for me! One day I'll get a quiet moment - however today I'm adding all the Home Assistant sensors/controls for our new Tesla! Absolutely amazing range of controls/sensors it has for HA!

Oh wow. I'm not jealous at all.

john_smith · 10 Dec 2022 at 16:21

katie279 said:
Hi John,

No worries - probably the quickest way is to just add it to your configuration.yaml file. Do you know where this is? (I can walk you through if not).

Below is what I have in my configuration.yaml file - just paste it right at the bottom and change the bits in caps to your ID and API Key

Code:

## Solar Output to PV Output shell_command: pvoutputcurl: > curl -d "d={{now().strftime("%Y%m%d")}}" -d "t={{now().strftime("%H:%M")}}" -d "v1={{ (states('sensor.pv_energy_today') | float * 1000) | int }}" -d "v2={{ states('sensor.pv_power') }}" -d "v6={{ states('sensor.grid_voltage') }}" -H "X-Pvoutput-SystemId: MY SYSTEM ID" -H "X-Pvoutput-Apikey: MY API KEY IN HERE" https://pvoutput.org/service/r2/addstatus.jsp

Thank you. Apologies got stuff going on in here and in the solar thread.

I’ll play when I get home later and keep questions going forward here.

john_smith · 10 Dec 2022 at 21:02

Copied your bits and no luck.

So changed the sensors and still get the errors

This is from the PVOutput icon under intergrations.

Retrying setup: PVOutput has no data available

My Shell Command

## Solar Output to PV Output
shell_command:
pvoutputcurl: >
curl -d "d={{now().strftime("%Y%m%d")}}"
-d "t={{now().strftime("%H:%M")}}"
-d "v1={{ (states('sensor.powerwall_site_import') | float * 1000) | int }}"
-d "v2={{ states('sensor.powerwall_solar_now') }}"
-d "v6={{ states('sensor.powerwall_site_now') }}"
-H "X-Pvoutput-SystemId: ID"
-H "X-Pvoutput-Apikey: API"
https://pvoutput.org/service/r2/addstatus.jsp

katie279 · 10 Dec 2022 at 21:09

john_smith said:
Copied your bits and no luck.

So changed the sensors and still get the errors

This is from the PVOutput icon under intergrations.

Retrying setup: PVOutput has no data available

My Shell Command

## Solar Output to PV Output
shell_command:
pvoutputcurl: >
curl -d "d={{now().strftime("%Y%m%d")}}"
-d "t={{now().strftime("%H:%M")}}"
-d "v1={{ (states('sensor.powerwall_site_import') | float * 1000) | int }}"
-d "v2={{ states('sensor.powerwall_solar_now') }}"
-d "v6={{ states('sensor.powerwall_site_now') }}"
-H "X-Pvoutput-SystemId: ID"
-H "X-Pvoutput-Apikey: API"
https://pvoutput.org/service/r2/addstatus.jsp

Ok start with the silly questions - are you inserting your correct ID and API in above? (Just checking you're not copying and pasting directly!)

I'd imagine this error means it's working fine, but there's nothing coming from your PV integration - apologies, remind me what your solar setup is again?

Above is pointing to a sensor called sensor.powerwall_solar_now and so on, so it might be you've got a different brand?

If you look at my example above, it's using the generic Home Assistant energy values:

## Solar Output to PV Output
shell_command:
pvoutputcurl: >
curl -d "d={{now().strftime("%Y%m%d")}}"
-d "t={{now().strftime("%H:%M")}}"
-d "v1={{ (states('sensor.pv_energy_today') | float * 1000) | int }}"
-d "v2={{ states('sensor.pv_power') }}"
-d "v6={{ states('sensor.grid_voltage') }}"
-H "X-Pvoutput-SystemId: KATIES_PVOUTPUTID"
-H "X-Pvoutput-Apikey: KATIES_API"
https://pvoutput.org/service/r2/addstatus.jsp

Quickest test is to see if you actually have a sensor called this (this is step 3)

Let me know if you're stuck and we can step through it

john_smith · 10 Dec 2022 at 21:16

Silly questions are fine, i'm out of my depth here

My Solar setup is "dumb" so I can't get anything from my inverter. However I do have a full myenergi setup and a powerwall. In the example above I used the (i think) right powerwall sensors to replace the ones you'd given me in the example.
